So I was never happy about two things on our build. Well, maybe more, but the point of this post it about two things in particular. The layout of the equipment pad and the fact that we had a pressure side cleaner with booster pump instead of a robot. The second item we took care of with our purchase of Earl our Dolphin Active 20. The equipment pad redo hinged on being able to remove the booster pump which we could now do.
Goals of the pad reno were to:
- Raise the pump and filter up out of the stones
- Remove the booster pump
- Maintain the pressure cleaner line as a return
- Allow more space for accessing the pump and filter
- Make the river rock deeper by removing grey rock which was right below the surface
- Remove a few of the 90's at the pad
- Vertically orient the SWCG to take up less space
Here is the original rough plumbing to the pad. The writing was on the wall for how disorganized it would be.
Then the original in process shot. The grey rock hides the poor plumbing layout below deck.
Then how the original layout ended up. Too tight, too low and unappealing to boot.
Then the new layout still exposed. There are lots of extra unused lines. Two for solar (probably won't do it, not a lot of surface area on the pavillion and orientation), two that just go outside of the retaining wall (won't be used) and one that is an extra line to the main drain should something happen to the current one.
The new layout with river rock.
The new layout up close. One nice feature of the valves is that even though they were installed without unions, as most are, they can be re-used by going on the outside of the fitting, which I believe is 2 1/2" (or 3") then reducing back down to the original diameter. Definitely takes longer to prime when the pump basket or filter are opened since the suction lines and pump are now all above ground more, but no worries.
The hanging equipment partition.
And backing away.
And from the main viewing direction. I'd like to build a roof for it with cedar shakes to match the pavillion, and maybe a sliding wall or door on the diving board side to keep the sun off of it, but for now, it's done and I'm much more satisfied.
Kreepy Krauly Legend pressure cleaner and Hayward 6060 booster pump now for sale!
